Honeywell Gas Detection

Honeywell Gas Detector: Acting as the nerve center of a modular gas detection network, the VA301CDS provides continuous monitoring of up to 96 inputs/outputs, on 3 distinct channels, at distances of up to 2000 feet.

Once installed, this highly customizable and powerful tool provides around the clock protection identifying hazards and triggering appropriate reactive measures such as ventilation activation.

The Modbus output can be converted to a BACnet output providing flexibility and plug & play like installation.

  • Backlit LCD display (122 x 32 dot matrix)
  • 65dbA audible alarm
  • DPDT programmable relays
  • Up to 96 transmitters/relay modules (VA301R)
  • Up to 126 zoning groups
  • 768 programmable events
  • Straight forward, user-friendly field modifications
  • Datalogging (128Mb SDcard)
  • BACnet/Ethernet available (VA301BDCM)
  • BACnet/IP available (VA301BDCM with ROUTERIP)
VA301C Applications:
  • Parking Garages
  • Loading Docks
  • Mechanical Rooms
  • Boiler Rooms
  • Freezers/Chillers
  • Swimming Pools
  • Hospitals
  • Fire Stations
